はじめに

　こんにちは。ネットワークエンジニアの「だいまる」です。

今回は、前回投稿したSR-MPLS TEのExplicit Pathの続きとなるDynamic Pathについて投稿していきたいと思います。

記事一覧（SR-MPLSシリーズ）

SR-MPLS TE Dynamic pathをCMLを使って実装してみた結果

構成図

　今回の実装で用いた構成は、前回同様の構成となります。
　TReXはトラフィックジェネレータを指し、Router1・Router6のルータはIOSとなっております。
　また、Router2〜Router5はIOS-XRとなっており、この4台でSR-MPLSを設定し、TEを実現します。

Dynamic Pathの設定

　Dynamic Pathの設定は、主に2つあります。1つ目はIGPを利用する場合、2つ目がTEメトリックを利用する場合です。
IGPメトリックを利用する場合は、OSPFやIS-ISなどで設定したメトリックを利用するので、policy配下に以下設定を投入することで完了します。

segment-routing
 traffic-eng
  policy <ポリシー名>
   candidate-paths
    preference <pref値>
     dynamic
      metric type igp

　そして、TEメトリックを利用する場合は、メトリックの設定を行い、「metric type igp」の部分を「metric type te」にすることで設定したメトリックを読み取り、トラフィック制御をしてくれます。

segment-routing
 traffic-eng
  interface <IF名>
   metric <metric値>
  policy <ポリシー名>
   candidate-paths
    preference <pref値>
     dynamic
      metric type te

　その上で、今回、実施した内容はOSPFメトリックで流れているトラフィック（Router2→Router4）をTEメトリックを図の通りに設定し、Router2→Router3→Router5→Router4の順で流れるように制御する。

　まず、事前状態の確認となります。
以下のログからわかるように適用されているPolicyは１つもありません（up/downのポリシーが0のため）。また、ルーティングテーブルを確認してもわかるように「10.0.1.4（ルータ4）」向けはSR-TEが適用されておらず、OSPFメトリックにより計算されています。（TI-LFA有効）

Sun May  7 10:03:54.087 UTC
RP/0/RP0/CPU0:Router2#show segment-routing traffic-eng policy summary
Sun May  7 10:03:57.147 UTC
SR-TE policy database summary:
----------------------------
Total policies: 0
  Operational: up 0 down 0
Per-Destination Policies Summary:
  Total configured: 0
  Operational: up 0 down 0
Per-Flow Policies Summary:
  Total configured: 0
  Operational: up 0 down 0
Total candidate paths: 0
  State: active 0 inactive 0

RP/0/RP0/CPU0:Router2#show route ipv4 10.0.1.4
Sun May  7 10:04:12.478 UTC
Routing entry for 10.0.1.4/32
  Known via "ospf 100", distance 110, metric 11, labeled SR, type intra area
  Installed May  7 10:02:00.224 for 00:02:12
  Routing Descriptor Blocks
    10.1.0.2, from 10.0.1.4, via GigabitEthernet0/0/0/0, Backup (TI-LFA)
      Repair Node(s): 10.0.1.3, 10.0.1.5
      Route metric is 211
    10.2.0.2, from 10.0.1.4, via GigabitEthernet0/0/0/1, Protected
      Route metric is 11
  No advertising protos.

　そして、各ルータでTEメトリックの設定を行った後、Router2で以下設定を投入し「10.0.1.4（ルータ4宛）」宛の経路はTEメトリックで計算するように適用しました。

RP/0/RP0/CPU0:Router2(config)#segment-routing traffic-eng
RP/0/RP0/CPU0:Router2(config-sr-te)#policy POLICY_TEST
RP/0/RP0/CPU0:Router2(config-sr-te-policy)#candidate-paths
RP/0/RP0/CPU0:Router2(config-sr-te-policy-path)#preference 100
RP/0/RP0/CPU0:Router2(config-sr-te-policy-path-pref)#dynamic
RP/0/RP0/CPU0:Router2(config-sr-te-pp-info)#metric type te
RP/0/RP0/CPU0:Router2(config-sr-te-pp-info)#exit
RP/0/RP0/CPU0:Router2(config-sr-te-policy-path)#preference 10
RP/0/RP0/CPU0:Router2(config-sr-te-policy-path-pref)#dynamic
RP/0/RP0/CPU0:Router2(config-sr-te-pp-info)#metric type igp
RP/0/RP0/CPU0:Router2(config-sr-te-pp-info)#commit
RP/0/RP0/CPU0:Router2(config-sr-te-pp-info)#end

　上記設定を投入後の状態を確認していくと、「srte_c_10_ep_10.0.1.4」が適用されており、TEメトリックが「active」かつ「valid」になっていることがわかります。また、IGPメトリックはpreference 10で設定しているため、「invalid」になっており、採用されていないことがわかります。
　また、先ほどはpolicyのup/downが全て0だったのに、数字が変化していることからPolicyが適用されていることが確実となります。
　そして、ルーティングテーブルもProtect/BackupとなっていたものがPolicy名になっています。

RP/0/RP0/CPU0:Router2#show segment-routing traffic-eng policy name srte_c_10_ep_10.0.1.4
Sun May  7 10:09:23.186 UTC

SR-TE policy database
---------------------

Color: 10, End-point: 10.0.1.4
  Name: srte_c_10_ep_10.0.1.4
  Status:
    Admin: up  Operational: up for 00:00:07 (since May  7 10:09:15.325)
  Candidate-paths:
    Preference: 100 (configuration) (active)
      Name: POLICY_TEST
      Requested BSID: dynamic
        Protection Type: protected-preferred
        Maximum SID Depth: 10
      Dynamic (valid)
        Metric Type: TE,   Path Accumulated Metric: 30
          16004 [Prefix-SID, 10.0.1.4]
    Preference: 10 (configuration)
      Name: POLICY_TEST
      Requested BSID: dynamic
        Protection Type: protected-preferred
        Maximum SID Depth: 10
      Dynamic (invalid)
      Last error: unresolved first label (16004)
        Metric Type: IGP,   Path Accumulated Metric: 0
  Attributes:
    Binding SID: 24028
    Forward Class: Not Configured
    Steering labeled-services disabled: no
    Steering BGP disabled: no
    IPv6 caps enable: yes
    Invalidation drop enabled: no

RP/0/RP0/CPU0:Router2#show segment-routing traffic-eng policy summary
Sun May  7 10:10:28.883 UTC

SR-TE policy database summary:
----------------------------

Total policies: 1
  Operational: up 1 down 0

Per-Destination Policies Summary:
  Total configured: 1
  Operational: up 1 down 0

Per-Flow Policies Summary:
  Total configured: 0
  Operational: up 0 down 0

Total candidate paths: 2
  State: active 1 inactive 1

RP/0/RP0/CPU0:Router2#show route ipv4 10.0.1.4
Sun May  7 10:12:41.219 UTC

Routing entry for 10.0.1.4/32
  Known via "ospf 100", distance 110, metric 11, labeled SR, label redist non FIB, type intra area
  Installed May  7 10:09:15.500 for 00:03:25
  Routing Descriptor Blocks
    10.0.1.4, from 10.0.1.4, via srte_c_10_ep_10.0.1.4
      Route metric is 11
  No advertising protos.

　上記の結果より、想定通りの経路制御ができていることがわかりました。では、Explicit Pathの時と同じく障害時の動作確認を行っていきましょう。

障害試験（リンク障害）

　リンク障害は、Router2ーRouter3のリンクを切断します。今回、CML GUIからリンクを切断することができることがわかったので、その機能を利用しました。
　結果としては、IGPであるOSPFやIS-ISと同じように経路の再計算が実施され、切り替わりましたが！！
TI-LFAが適用されているはずなのになぜか8秒ぐらい切り替えに時間がかかっているので、原因確認中です。。。

　まずは、事前状態のログを貼り付けていきます。Policyの状態を確認すると、Router3→Router5→Router4経由の経路が最適になっていることがわかります。

RP/0/RP0/CPU0:Router2#show segment-routing traffic-eng policy name srte_c_10_ep_10.0.1.4
Sun May  7 13:05:07.545 UTC

SR-TE policy database
---------------------

Color: 10, End-point: 10.0.1.4
  Name: srte_c_10_ep_10.0.1.4
  Status:
    Admin: up  Operational: up for 00:15:23 (since May  7 12:49:43.776)
  Candidate-paths:
    Preference: 200 (configuration) (active)
      Name: POLICY_TEST
      Requested BSID: dynamic
        Protection Type: protected-preferred
        Maximum SID Depth: 10
      Dynamic (valid)
        Metric Type: TE,   Path Accumulated Metric: 30
          16003 [Prefix-SID, 10.0.1.3]
          16005 [Prefix-SID, 10.0.1.5]
          16004 [Prefix-SID, 10.0.1.4]
    Preference: 100 (configuration)
      Name: POLICY_TEST
      Requested BSID: dynamic
        Protection Type: protected-preferred
        Maximum SID Depth: 10
      Dynamic (invalid)
      Last error: unresolved first label (16004)
        Metric Type: IGP,   Path Accumulated Metric: 0
  Attributes:
    Binding SID: 24012
    Forward Class: Not Configured
    Steering labeled-services disabled: no
    Steering BGP disabled: no
    IPv6 caps enable: yes
    Invalidation drop enabled: no

RP/0/RP0/CPU0:Router2#show route ipv4 10.0.1.4
Sun May  7 13:05:13.360 UTC
Routing entry for 10.0.1.4/32
  Known via "ospf 100", distance 110, metric 11, labeled SR, label redist non FIB, type intra area
  Installed May  7 13:03:02.519 for 00:02:10
  Routing Descriptor Blocks
    10.0.1.4, from 10.0.1.4, via srte_c_10_ep_10.0.1.4
      Route metric is 11
  No advertising protos.

　そして、リンク断を発生させると、以下デバッグログが出ています。

RP/0/RP0/CPU0:Router2#RP/0/RP0/CPU0:May  7 13:06:52.356 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.356 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.356 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.356 UTC: xtc_agent[1274]: DBG-Policy-LSP:_xtc_policy_verify:2441  [LSP-ID: 8 POL-ID: 1] Verification indicated no path change
RP/0/RP0/CPU0:May  7 13:06:52.356 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4023 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 8 POL-ID: 1] SL egress paths verify: 16003, path_count=2, sl_changed=0,
RP/0/RP0/CPU0:May  7 13:06:52.356 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 8 POL-ID: 1] LSP egress paths verify: total=1, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.356 UTC: ospf[1027]: %ROUTING-OSPF-5-ADJCHG : Process 100, Nbr 10.0.1.3 on GigabitEthernet0/0/0/0 in area 0 from FULL to DOWN, Neighbor Down: interface down or detached, vrf default vrfid 0x60000000
LC/0/0/CPU0:May  7 13:06:52.353 UTC: ifmgr[260]: %PKT_INFRA-LINK-3-UPDOWN : Interface GigabitEthernet0/0/0/0, changed state to Down
LC/0/0/CPU0:May  7 13:06:52.353 UTC: ifmgr[260]: %PKT_INFRA-LINEPROTO-5-UPDOWN : Line protocol on Interface GigabitEthernet0/0/0/0, changed state to Down
RP/0/RP0/CPU0:May  7 13:06:52.418 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.418 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.418 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.419 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4023 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 8 POL-ID: 1] SL egress paths verify: 16003, path_count=2, sl_changed=0,
RP/0/RP0/CPU0:May  7 13:06:52.419 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 8 POL-ID: 1] LSP egress paths verify: total=1, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.419 UTC: xtc_agent[1274]: DBG-Policy-LSP:_xtc_policy_verify:2473  [LSP-ID: 8 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:52.419 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_create:815  [LSP-ID: 0 POL-ID: 0] LSP created for POL-ID: 1, num LSPs: 2
RP/0/RP0/CPU0:May  7 13:06:52.419 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_ident:1138  [LSP-ID: 9 POL-ID: 1] Set ident
RP/0/RP0/CPU0:May  7 13:06:52.419 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_cpath:1206  [LSP-ID: 9 POL-ID: 1] Set CP-ID: 2
RP/0/RP0/CPU0:May  7 13:06:52.419 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_register:3706  [LSP-ID: 9 POL-ID: 1] Prefix 24001, awaiting response from FIB about egress paths
RP/0/RP0/CPU0:May  7 13:06:52.419 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124  [LSP-ID: 9 POL-ID: 1] Current state Init, event posted: Egress paths
RP/0/RP0/CPU0:May  7 13:06:52.420 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.420 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.420 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2106  [LSP-ID: 9 POL-ID: 1] reopt_lsp passed verification, current_lsp first_hops_valid=1,
RP/0/RP0/CPU0:May  7 13:06:52.421 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.421 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.421 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.421 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.421 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.421 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2106  [LSP-ID: 9 POL-ID: 1] reopt_lsp passed verification, current_lsp first_hops_valid=1,
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 0
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2106  [LSP-ID: 9 POL-ID: 1] reopt_lsp passed verification, current_lsp first_hops_valid=0,
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4023 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 8 POL-ID: 1] SL egress paths verify: 16003, path_count=0, sl_changed=1,
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4028 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 8 POL-ID: 1] No valid egress paths
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 8 POL-ID: 1] LSP egress paths verify: total=1, invalid=1, changed=1, drsn=7,
RP/0/RP0/CPU0:May  7 13:06:52.468 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_invalidated:1711  [LSP-ID: 8 POL-ID: 1] Invalidated: yes
RP/0/RP0/CPU0:May  7 13:06:52.470 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.470 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.470 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 0
RP/0/RP0/CPU0:May  7 13:06:52.470 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.470 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.470 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.470 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:52.470 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 1 seconds
RP/0/RP0/CPU0:May  7 13:06:52.484 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.484 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.484 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:52.484 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.484 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.484 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.484 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:52.484 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:52.485 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 2 seconds
RP/0/RP0/CPU0:May  7 13:06:52.486 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.486 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.486 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:52.486 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.486 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.486 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.486 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:52.486 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:52.486 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 4 seconds
RP/0/RP0/CPU0:May  7 13:06:52.505 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.505 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.505 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:52.505 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.505 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.505 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.505 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:52.505 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:52.505 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 8 seconds
RP/0/RP0/CPU0:May  7 13:06:52.567 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.567 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.567 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:52.568 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.568 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.568 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.568 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:52.568 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:52.568 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 16 seconds
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 32 seconds
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.571 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.572 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:52.572 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:52.572 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 60 seconds
RP/0/RP0/CPU0:May  7 13:06:52.644 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:52.644 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:52.644 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:52.644 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:52.644 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:52.644 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:52.644 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:52.644 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:52.644 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 60 seconds
RP/0/RP0/CPU0:May  7 13:06:53.166 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:53.166 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:53.166 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:53.166 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:53.166 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:53.166 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:53.166 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:53.166 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:53.166 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 60 seconds
RP/0/RP0/CPU0:May  7 13:06:53.267 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:53.267 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:53.267 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sl_pathflags_changed:2237  [LSP-ID: 8 POL-ID: 1] Number of egress paths changed from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:53.267 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:3970 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Skip egress path verification
RP/0/RP0/CPU0:May  7 13:06:53.267 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=0, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:53.267 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:53.267 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:53.267 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_verify_reopt_lsp:2093  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:53.267 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_reschedule:1627  [POL-ID: 1] [color: 10] Policy cannot be updated, rescheduling VERIFY in 60 seconds
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_populate:3846  [LSP-ID: 9 POL-ID: 1] Prefix 24001, set new egress path(s)
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_lsd_rewrite_fill_path_moi:476 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] Fill path moi path flag 0x0, load metric 64, num_of_labels : 3
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_lsd_rewrite_create_lsp_paths:973  [LSP-ID: 9 POL-ID: 1] create_lsp_paths: SL num_valid_mois=1,
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_validate_egress_info:2415  [LSP-ID: 9 POL-ID: 1] SL [idx: 0] path [idx: 0] version changed 1 -> 4
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124  [LSP-ID: 9 POL-ID: 1] Current state Egress paths pending, event posted: Label alloc
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_label_alloc_cb:1098  [LSP-ID: 9 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_local_label:1277  [LSP-ID: 9 POL-ID: 1] Set local label: 24006
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124  [LSP-ID: 9 POL-ID: 1] Current state Label allocation pending, event posted: Label RW
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_label_rewrite_cb:1146  [LSP-ID: 9 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.420 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_lsd_rewrite_fill_label_fpi_data:1026  [LSP-ID: 9 POL-ID: 1] Filled label (24006) FPI data. Label flags: 0x00000000
RP/0/RP0/CPU0:May  7 13:06:53.421 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124 (LSP: 9 T: 1)  [LSP-ID: 9 POL-ID: 1] Current state Label rewrite pending, event posted: Start install timer
RP/0/RP0/CPU0:May  7 13:06:53.421 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_start_install_timer_cb:1448 (LSP: 9 T: 1)  [LSP-ID: 9 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.421 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_start_timer:1569 (LSP: 9 T: 1)  [LSP-ID: 9 POL-ID: 1] Starting install timer with 0 sec delay
RP/0/RP0/CPU0:May  7 13:06:53.423 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_install_timer_cb:642  [LSP-ID: 9 POL-ID: 1] Install timer expired
RP/0/RP0/CPU0:May  7 13:06:53.423 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_bfd_lsp_is_session_needed:629  [LSP-ID: 9 POL-ID: 1] BFD is_session_needed: cpath_needed:0, is_cleaning:0, needs_cleaning:0, label_rw:1
RP/0/RP0/CPU0:May  7 13:06:53.423 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124  [LSP-ID: 9 POL-ID: 1] Current state Install timer pending, event posted: Tunnel RW
RP/0/RP0/CPU0:May  7 13:06:53.423 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_tunnel_rewrite_cb:1257  [LSP-ID: 9 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.423 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_lsd_rewrite_fill_tunnel_moi:1325  [LSP-ID: 9 POL-ID: 1] Filled tunnel MOI. Label: 24006, Forward class: 0, Flags: 0x00000000, Ext-Flags: 0x00000080
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124 (LSP: 9 T: 1)  [LSP-ID: 9 POL-ID: 1] Current state Tunnel rewrite pending, event posted: Success
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_programmed_cb:1058 (LSP: 9 T: 1)  [LSP-ID: 9 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_set_current_lsp:1640 (LSP: 9 T: 1)  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Set current LSP to [LSP-ID: 9] (previous [LSP-ID: 8])
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_bsid:1405 (LSP: 9 T: 1)  [LSP-ID: 9 POL-ID: 1] Set BSID-ID: 2, increment ref count from 1 to 2
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_clear_bsid:1430 (LSP: 9 T: 1)  [LSP-ID: 8 POL-ID: 1] Cleared BSID-ID: 2, decrement ref count from 2 to 1
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_transfer_data:2959 (LSP: 9 T: 1)  [LSP-ID: 8 POL-ID: 1] Transferred BSID data to [LSP-ID: 9 POL-ID: 1]
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_tear_down:1306 (LSP: 9 T: 1)  [LSP-ID: 8 POL-ID: 1] Tearing down LSP
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124 (LSP: 9 T: 1)  [LSP-ID: 8 POL-ID: 1] Current state Programmed, event posted: Start cleanup timer
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_start_cleanup_timer_cb:1584 (LSP: 9 T: 1)  [LSP-ID: 8 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_start_timer:1569 (LSP: 9 T: 1)  [LSP-ID: 8 POL-ID: 1] Starting cleanup timer with 0 sec delay
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_delete_chkpt_cb:1614 (LSP: 9 T: 1)  [LSP-ID: 8 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:382  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing VERIFY action
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-Event:_xtc_policy_verify:2307  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing verification
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-State:xtc_policy_pcalc_dynamic:2129  Beginning path computation of path-option index 0 Dynamic dynamic
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_state_fixup:395  [LSP-ID: 9 POL-ID: 1] LSP path differs from CP-ID: 2 path: state=0xd
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4023 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] SL egress paths verify: 24001, path_count=1, sl_changed=0,
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_verify_mpls:4041 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 9 POL-ID: 1] LSP egress paths verify: total=1, invalid=0, changed=0, drsn=0,
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:_xtc_policy_verify:2473  [LSP-ID: 9 POL-ID: 1] RW needed due to changes in: topology: yes, FIB: no, force: no, LSP: no
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_invalidated:1711  [LSP-ID: 8 POL-ID: 1] Invalidated: yes
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_needs_cleaning_up:1678  [LSP-ID: 8 POL-ID: 1] Needs cleaning up: yes
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_create:815  [LSP-ID: 0 POL-ID: 0] LSP created for POL-ID: 1, num LSPs: 3
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_ident:1138  [LSP-ID: 10 POL-ID: 1] Set ident
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_cpath:1206  [LSP-ID: 10 POL-ID: 1] Set CP-ID: 2
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_egress_paths_populate:3846  [LSP-ID: 10 POL-ID: 1] Prefix 16004, set new egress path(s)
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_lsd_rewrite_fill_path_moi:476 (Policy: srte_c_10_ep_10.0.1.4 #1)  [LSP-ID: 10 POL-ID: 1] Fill path moi path flag 0x0, load metric 64, num_of_labels : 0
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_lsd_rewrite_create_lsp_paths:973  [LSP-ID: 10 POL-ID: 1] create_lsp_paths: SL num_valid_mois=1,
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_validate_egress_info:2415  [LSP-ID: 10 POL-ID: 1] SL [idx: 0] path [idx: 0] version changed 1 -> 4
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124  [LSP-ID: 10 POL-ID: 1] Current state Init, event posted: Label alloc
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_label_alloc_cb:1098  [LSP-ID: 10 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:393  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing NOTIFY action
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_notify_client_id_list_build:4165  [POL-ID: 1] [C: 10, EP: 10.0.1.4] notify generation not changed
RP/0/RP0/CPU0:May  7 13:06:53.424 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_autoroute_populate_pol:2165  [LSP-ID: 9 POL-ID: 1] autoroute update,  bsid:24012,
RP/0/RP0/CPU0:May  7 13:06:53.426 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_local_label:1277  [LSP-ID: 10 POL-ID: 1] Set local label: 24017
RP/0/RP0/CPU0:May  7 13:06:53.426 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124  [LSP-ID: 10 POL-ID: 1] Current state Label allocation pending, event posted: Label RW
RP/0/RP0/CPU0:May  7 13:06:53.426 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_label_rewrite_cb:1146  [LSP-ID: 10 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.426 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_lsd_rewrite_fill_label_fpi_data:1026  [LSP-ID: 10 POL-ID: 1] Filled label (24017) FPI data. Label flags: 0x00000000
RP/0/RP0/CPU0:May  7 13:06:53.426 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_cleanup_timer_cb:668  [LSP-ID: 8 POL-ID: 1] Cleanup timer expired
RP/0/RP0/CPU0:May  7 13:06:53.426 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124  [LSP-ID: 8 POL-ID: 1] Current state Cleanup timer pending, event posted: Cleanup label RW
RP/0/RP0/CPU0:May  7 13:06:53.426 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_label_rewrite_cleanup_cb:1314  [LSP-ID: 8 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.426 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_lsd_rewrite_fill_label_fpi_data:1026  [LSP-ID: 8 POL-ID: 1] Filled label (24018) FPI data. Label flags: 0x00000000
RP/0/RP0/CPU0:May  7 13:06:53.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124 (LSP: 10 T: 1)  [LSP-ID: 10 POL-ID: 1] Current state Label rewrite pending, event posted: Start install timer
RP/0/RP0/CPU0:May  7 13:06:53.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_start_install_timer_cb:1448 (LSP: 10 T: 1)  [LSP-ID: 10 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_start_timer:1569 (LSP: 10 T: 1)  [LSP-ID: 10 POL-ID: 1] Starting install timer with 10 sec delay
RP/0/RP0/CPU0:May  7 13:06:53.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124 (LSP: 8 T: 1)  [LSP-ID: 8 POL-ID: 1] Current state Label rewrite cleanup pending, event posted: Cleanup done
RP/0/RP0/CPU0:May  7 13:06:53.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_deleted_cb:1033 (LSP: 8 T: 1)  [LSP-ID: 8 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:06:53.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_cleanup:972 (LSP: 8 T: 1)  [LSP-ID: 8 POL-ID: 1] LSP cleanup
RP/0/RP0/CPU0:May  7 13:06:53.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_local_label:1277 (LSP: 8 T: 1)  [LSP-ID: 8 POL-ID: 1] Set local label: 1048577
RP/0/RP0/CPU0:May  7 13:06:53.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_start_timer:1569 (LSP: 8 T: 1)  [LSP-ID: 8 POL-ID: 1] Starting delete timer with 0 sec delay
RP/0/RP0/CPU0:May  7 13:06:53.429 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_delete_timer_cb:683  [LSP-ID: 8 POL-ID: 1] Delete timer expired
RP/0/RP0/CPU0:May  7 13:06:53.429 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_free:1057  [LSP-ID: 8 POL-ID: 1] LSP freed
RP/0/RP0/CPU0:May  7 13:07:03.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_install_timer_cb:642  [LSP-ID: 10 POL-ID: 1] Install timer expired
RP/0/RP0/CPU0:May  7 13:07:03.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_bfd_lsp_is_session_needed:629  [LSP-ID: 10 POL-ID: 1] BFD is_session_needed: cpath_needed:0, is_cleaning:0, needs_cleaning:0, label_rw:1
RP/0/RP0/CPU0:May  7 13:07:03.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124  [LSP-ID: 10 POL-ID: 1] Current state Install timer pending, event posted: Tunnel RW
RP/0/RP0/CPU0:May  7 13:07:03.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_tunnel_rewrite_cb:1257  [LSP-ID: 10 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:07:03.427 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_lsd_rewrite_fill_tunnel_moi:1325  [LSP-ID: 10 POL-ID: 1] Filled tunnel MOI. Label: 24017, Forward class: 0, Flags: 0x00000000, Ext-Flags: 0x00000080
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124 (LSP: 10 T: 1)  [LSP-ID: 10 POL-ID: 1] Current state Tunnel rewrite pending, event posted: Success
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_programmed_cb:1058 (LSP: 10 T: 1)  [LSP-ID: 10 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_set_current_lsp:1640 (LSP: 10 T: 1)  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Set current LSP to [LSP-ID: 10] (previous [LSP-ID: 9])
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_set_bsid:1405 (LSP: 10 T: 1)  [LSP-ID: 10 POL-ID: 1] Set BSID-ID: 2, increment ref count from 1 to 2
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_clear_bsid:1430 (LSP: 10 T: 1)  [LSP-ID: 9 POL-ID: 1] Cleared BSID-ID: 2, decrement ref count from 2 to 1
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_transfer_data:2959 (LSP: 10 T: 1)  [LSP-ID: 9 POL-ID: 1] Transferred BSID data to [LSP-ID: 10 POL-ID: 1]
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_tear_down:1306 (LSP: 10 T: 1)  [LSP-ID: 9 POL-ID: 1] Tearing down LSP
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_post_event:124 (LSP: 10 T: 1)  [LSP-ID: 9 POL-ID: 1] Current state Programmed, event posted: Start cleanup timer
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_start_cleanup_timer_cb:1584 (LSP: 10 T: 1)  [LSP-ID: 9 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_start_timer:1569 (LSP: 10 T: 1)  [LSP-ID: 9 POL-ID: 1] Starting cleanup timer with 10 sec delay
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_lsp_sm_delete_chkpt_cb:1614 (LSP: 10 T: 1)  [LSP-ID: 9 POL-ID: 1] Entered FSM callback
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-Event:xtc_policy_schedule_handler:393  [POL-ID: 1] [C: 10, EP: 10.0.1.4] Processing NOTIFY action
RP/0/RP0/CPU0:May  7 13:07:03.428 UTC: xtc_agent[1274]: DBG-Policy-LSP:xtc_policy_autoroute_populate_pol:2165  [LSP-ID: 10 POL-ID: 1] autoroute update,  bsid:24012,

　上記デバッグログが出て、切り替わった後は、以下の状態となっております。
policyの状態を見ていると、Router4に直接トラフィックが流れることに変わっています。

RP/0/RP0/CPU0:Router2#show segment-routing traffic-eng policy name srte_c_10_ep_10.0.1.4
Sun May  7 13:07:20.935 UTC

SR-TE policy database
---------------------

Color: 10, End-point: 10.0.1.4
  Name: srte_c_10_ep_10.0.1.4
  Status:
    Admin: up  Operational: up for 00:17:37 (since May  7 12:49:43.776)
  Candidate-paths:
    Preference: 200 (configuration) (active)
      Name: POLICY_TEST
      Requested BSID: dynamic
        Protection Type: protected-preferred
        Maximum SID Depth: 10
      Dynamic (valid)
        Metric Type: TE,   Path Accumulated Metric: 50
          16004 [Prefix-SID, 10.0.1.4]
    Preference: 100 (configuration)
      Name: POLICY_TEST
      Requested BSID: dynamic
        Protection Type: protected-preferred
        Maximum SID Depth: 10
      Dynamic (invalid)
      Last error: unresolved first label (16004)
        Metric Type: IGP,   Path Accumulated Metric: 0
  Attributes:
    Binding SID: 24012
    Forward Class: Not Configured
    Steering labeled-services disabled: no
    Steering BGP disabled: no
    IPv6 caps enable: yes
    Invalidation drop enabled: no

RP/0/RP0/CPU0:Router2#show route ipv4 10.0.1.4
Sun May  7 13:07:23.270 UTC

Routing entry for 10.0.1.4/32
  Known via "ospf 100", distance 110, metric 11, labeled SR, label redist non FIB, type intra area
  Installed May  7 13:03:02.519 for 00:04:20
  Routing Descriptor Blocks
    10.0.1.4, from 10.0.1.4, via srte_c_10_ep_10.0.1.4
      Route metric is 11
  No advertising protos.

最後に

　実装してみて結構文字数が多くなるかと思っていたのですが、意外とすんなり問題なく通ってしまったので少し短い記事となってしまいました。
　次回は、SR-MPLSについての概要編を投稿していき、インプット・アウトプットを繰り返すうちにやってみたいと思ったことがあれば、そこをシリーズの続きとして投稿していこうかと思います。

技術 ネットワーク セグメントルーティング
#Cisco #IOSXR #Network #Segment-Routing #SR #SRMPLS #ネットワーク
  • URLをコピーしました！

この記事を書いた人

daimaru_techのアバター daimaru_tech

関連記事

コメント

コメントする

目次
